Pantographs & Loading Arms

Cla-Val is a leading supplier of pantographs for military fueling and defueling applications.

The Cla-Val Model 850AF Pantograph is the ultimate aviation fueling device. Hard-piped to eliminate the liabilities associated with rubber hose, the Cla-Val 850AF Pantograph sets the industry standard for maintenance-free operation, higher flow rates, and design versatility in refueling systems.

Cla-Val Pantographs utilize our own refueling nozzles for superior fuel delivery and are available in a variety of configurations, including:

• “In the Box”: stored in an underground pit for easy one-man operation
• “Wide Body”: easy, one-man operation with a long reach connection and smooth operating swivel joints
• “High Reach”: suitable for under wing refueling up to 5.7m/19 feet
• “Hot Refueling”: for flight line applications, rigid tube design with smoother swivel joints reaching up to 30m/100 feet
